Miller XMT® 400 ArcReach® Multi-Process Welder, Tweco®, Stick/TIG Remote Pkg (208-575 V, 1/3PH) #951000114

Part Numbers: 951000114

Included with your purchase: ()

Miller XMT® 400 ArcReach® Multi-Process Welder, Tweco®, Stick/TIG Remote Pkg (208-575 V, 1/3PH) #951000114
Miller XMT® 400 ArcReach® Multi-Process ...
Miller Classic Series Welding Helmet with ClearLight™ Lens Technology, VS Black #287803
FREE!
Miller Classic Series Welding Helmet wit...
Welders Supply cup holder
FREE!
Welders Supply Magnetic Cup Holder
Black Stallion Split Cowhide Gloves
FREE!
Black Stallion Split Cowhide Stick Glove...
Choose Options
American Welder T-Shirt - Back
FREE!
Welders Supply T-Shirt & Stickers
$8,938.00 + Free Shipping
$8,938.00 + Free Shipping

Call 844-682-0205 or CHAT for more options

Welding type:

MIG

MIG

TIG

TIG

Stick

Stick

Power supply:

220V Single Phase

220V Single Phase

220V 3 Phase

220V 3 Phase

460V

460V

Material type:

Mild Steel

Mild Steel

Stainless Steel

Stainless Steel

Aluminum

Aluminum

  • TIG/stick remote pendant includedTIG/Stick Remote
  • Multi-process MIG/TIG/stick welding machineMulti-Process Welding
  • Lightweight, portable welding power sourcePortable & Lightweight
  • 208-575 V Input
  • 1-Phase or 3-Phase Input
  • 10–38 V, 15–425 A Welding Output Range10–38 VDC, 15–425 A Output
  • Miller True Blue 3-Year WarrantyMiller 3-Year Warranty

Miller XMT® 400 ArcReach® Multi-Process Welding Machine, Stick/TIG Remote Package (208-575 V, 1PH /3PH) #951000114

Miller’s XMT® 400 ArcReach® Multi-Process is the smallest, lightest multi-process welding machine in its amperage class and provides industry-leading arc performance with dedicated processes for Stick, TIG, FCAW and MIG welding. Get power from anywhere with Auto-Line™ Technology and make remote voltage adjustments with the arc on with ArcReach® & AWW™ technologies. The Stick/TIG Package brings an ArcReach® Stick/TIG Remote for remote weld setting changes. Built on the foundation of the XMT® 350, the XMT® 400 continues Miller’s legacy of excellent performance and reliability.

Download literature of this machine:

Miller True Blue warranty

What's Included:

  • XMT 400 ArcReach power source
  • ArcReach® Stick/TIG Remote

Processes:

  • MIG (GMAW)
  • Pulsed MIG (GMAW-P)*
  • RMD®*
  • Stick (SMAW)
  • TIG (GTAW)
  • Flux-cored (FCAW)
  • Air carbon arc cutting and gouging (CAC-A)
  • Rated: 5/16-inch
  • Induction heating**

*Available with ArcReach Smart Feeder only.
**Available with ArcReach Heater only.

Applications:

  • Construction
  • Shipbuilding
  • Power generation plants
  • Rental fleets
  • Maintenance repair operations (MRO)
  • Fabrication
Miller ArcReach technology for XMT 400 lets welders communicate with the power source without a cord

Weld Away From the Power Source


Highlights

  • ArcReach® Technology: Increase job site productivity and efficiency by making voltage adjustments remotely or at the ArcReach® wire feeder.
  • Dedicated Weld Processes: Dial in the exact arc you need with industry-leading arc performance across Stick, TIG, FCAW and MIG processes.
  • Auto-Process Select™: Decrease the chance of using incorrect weld processes with automatic process selection based on polarity.
  • Wind Tunnel Technology™: Internal airflow to protect electrical components and PC boards from dirt, dust & debris.
  • Auto-Line™ Technology: Automatically calibrates for proper operation when connected to any primary input from 208-575 V w/o requiring manual linking.
  • Portable, Lightweight Stick/TIG Remote: Lets you change weld settings in your work area, eliminating extra trips & control cords to save time & money.

Benefits of the XMT 400 ArcReach #951000114:

  • ArcReach® technology enables weld operators to adjust parameters remotely or at the wire feeder rather than returning to the power source, reducing slip, trip, and fall hazards.
  • Automatic control panel lockout prevents unintended parameter adjustments by other workers on the job site.
  • Adjust While Welding (AWW™) allows welders to modify settings while the arc is active for faster, easier adjustments. Miller is the exclusive provider of this advanced capability.
  • ArcReach® heater compatibility empowers operators to handle preheating and bake-out tasks up to 600°F.
  • Designed for extreme mobility, the XMT® 400 is the lightest and most compact machine in its amperage class.
Miller XMT® 400 ArcReach® Multi-Process Welder - Key Features

Fast, Free Shipping & Easy Returns

At Welders Supply, we offer hassle-free shipping and returns. If you're not entirely satisfied, simply return the product within 14 days for an exchange, credit, or refund. Trust us to make your shopping experience seamless and worry-free. For any questions, our customer service team is just a call away at 1-844-682-0205.

Shop Welders Supply for the best prices on MIG, TIG, Stick and Gas welders from Miller & other top brands.
XMT® 400 ArcReach®, Tweco® (Stick/TIG Remote Pkg) - Specifications
Welding Processes Air Carbon Arc Cutting and Gouging (CAC-A)
Flux Cored (FCAW)
MIG (GMAW)
Multiprocess
Pulsed MIG (GMAW-P)
Regulated Metal Deposition (RMD)
Stick (SMAW)
TIG (GTAW)
Industries Interests Construction and Fabrication
Heavy Equipment
Shipbuilding
Amperage 15 A - 425 A
Weldable Metals Aluminum
Specialty Metals
Stainless Steel
Steel
Input Voltage 208 V
208/230/460 V
220/208 V
220/230/240 V
380/400 V
380/400/440 V
460 V
460/480 V
575 V
575/600 V
Rated Carbon Diameter 5/16 in (7.9 mm)
Input Phase 1- and 3-Phase
Input Hz 50/60 Hz
Current Type DC
Max Open Circuit Voltage 91 VDC
Metal Type Most Metals
Voltage Min 10 VDC
Voltage Max 38 VDC
Welding Mode CC/CV
Portability Handle(s)
Applications Boat/Yacht
Fabrication
Field Welding
Industrial Welding
Structural Welding
Warranty 3 Years
Miller's True Blue Warranty



SHIPPING DIMENSIONS

Height: 17.25 Inches
Width: 12.25 Inches
Length: 20.25 Inches
Weight: 75 Lb(s) 0 Oz
