Hypertherm Powermax 25' SmartSYNC 180° Robotic/Mini Torch #059734

Name: Powermax 25' SmartSYNC 180° Robotic/Mini Torch #059734
Brand: Hypertherm
SKU: 059734

Hypertherm Powermax 7.6 m (25' ) SmartSYNC 180° Robotic/Mini Torch #059734

For robotic jobs

The light weight, small size, and built-in positioning features of SmartSYNC robotic/mini torches enable easy integration and operation with light robot arms. Optional clamps and teach tools speed up integration.

Compatible with Hypertherm's SmartSYNC consumable cartridges.

Maximize performance

Tackle a wide range of jobs with easily interchangeable torch styles and application-specific Hypertherm cartridge consumables for various types of cutting and gouging.
Reduce training time with simplified set up and consistent performance.
Time-saving torch controls allow the operator to adjust the amperage on the fly and change consumables and applications without returning to the power supply.

Industry-leading reliability

SmartSYNC™ torches are engineered for rugged, industrial environments.
SpringStart™ technology ensures consistent starting and a more reliable torch.
Industry-leading reliability reduces production downtime.

Browse all Hypertherm Powermax SYNC plasma cutters, SmartSYNC torches and consumable cartridges available online from Welders Supply.

All Hypertherm SmartSYNC Torches
	Hand torches		Machine torches	Robotic/Mini torches
	75°	15°	180°	180°	90°	45°
15ft (4.5 m)				059733
25 ft (7.6 m)	059726	059723	059719	059734	059731	059729
35 ft (10.7 m)			059720
50 ft (15.2 m)	059727	059724	059721	059735	059732	059730
75 ft (22.8 m)	059728	059725	059722

SmartSYNC 180° Robotic/Mini Torch #059734 - Specifications
Torch type	Robotic/Mini
Lead length	25 ft (7.6 m)
Torch angle	180°
Compatible plasma cutters	All Hypertherm Powermax SYNC plasma cutter systems
Compatible consumables	All Hypertherm SmartSync consumable cartridges
Consumable change time	~10 seconds

NEW Hypertherm SmartSYNC Series

SmartSYNC™ torch automatically adjusts the amperage and chooses the right cutting mode.Hypertherm Powermax SYNC Explained Hypertherm Powermax SYNC Cartridge Installation When to Change Powermax SmartSYNC Cartridges

Accessories

Powermax 15' SmartSYNC 180° Robotic/Mini Torc...

$873.60

View

Hypertherm Powermax SmartSYNC Robotic/Mini Torch

Powermax 25' SmartSYNC 45° Robotic/Mini Torch...

$953.60

View

Powermax 25' SmartSYNC 90° Robotic/Mini Torch...

$953.60

View

Powermax 50' SmartSYNC 180° Robotic/Mini Torc...

$1,175.20

View

Powermax 50' SmartSYNC 45° Robotic/Mini Torch...

$1,175.20

View

Powermax 50' SmartSYNC 90° Robotic/Mini Torch...

$1,175.20

View

Powermax 75' SmartSYNC 45° Robotic/Mini Torch...

$1,236.70

View

Powermax 75' SmartSYNC 90° Robotic/Mini Torch...

$1,236.70

View

Powermax105 SYNC power supply, 200-600V 3-PH, CSA, plus CPC and serial ports - 059706

Powermax105 SYNC Plasma Cutter w/ CPC & Seria...

$6,550.00

View

Powermax105 SYNC w/ CPC & serial ports & torch, 25

Powermax105 SYNC Plasma Cutter w/ CPC & Seria...

$7,350.00

View

Powermax105 SYNC system, 200-600V, 3-PH, CSA, CPC and Serial ports, 180 degree torch, 10.7m (35

Powermax105 SYNC Plasma Cutter w/ CPC & Seria...

$7,450.00

View

Powermax105 SYNC power supply, 200-600V 3-PH, CSA, plus CPC port - 059705

Powermax105 SYNC Plasma Cutter w/ CPC Port - ...

$6,350.00

View

Powermax105 SYNC system, 200-600V 3-PH, CSA, CPC port, 75 degree handheld torch, 7.6m (25

Powermax105 SYNC Plasma Cutter w/ CPC Port, 2...

$7,000.00

View

Powermax105 SYNC w/ CPC port & machine torch, 25

Powermax105 SYNC Plasma Cutter w/ CPC Port, 2...

$7,150.00

View

Powermax105 SYNC Plasma Cutter w/ CPC Port, 2...

$7,300.00

View

Powermax105 SYNC system, 200-600V 3-PH, CSA, CPC port, 75 degree handheld torch, 15.2m (50

Powermax105 SYNC Plasma Cutter w/ CPC Port, 5...

$7,300.00

View

Powermax105 SYNC w/ CPC port & machine torch, 50

Powermax105 SYNC Plasma Cutter w/ CPC Port, 5...

$7,450.00

View

Powermax105 SYNC Plasma Cutter w/ CPC Port, 5...

$7,600.00

View

Powermax105 SYNC w/ CPC port & hand torches,7.6 m (25

Powermax105 SYNC Plasma Cutter w/ CPC Port, 7...

$7,750.00

View

Powermax105 SYNC w/ CPC port & torches, 35

Powermax105 SYNC Plasma Cutter w/ CPC Port, H...

$8,100.00

View

Powermax65 SYNC system, 200-600V, 1/3-PH, CSA, CPC & Serial Ports, 180 degree torch, 7.6 (25

Powermax65 SYNC Plasma Cutter w/ CPC & Serial...

$4,500.00

View

Powermax65 SYNC system, 200-600V, 1/3-PH, CSA, CPC & Serial Ports, 180 degree torch, 10.7m (35

Powermax65 SYNC Plasma Cutter w/ CPC & Serial...

$4,525.00

View

Hypertherm Powermax65 SYNC, 200-600V 1/3 PH, CSA Plus CPC & Serial Ports- 083373 Side

Powermax65 SYNC Plasma Cutter w/ CPC & Serial...

$3,775.00

View

Powermax65 SYNC system, 200-600V 1/3-PH, CSA, CPC port, 75 degree handheld torch, 7.6m (25

Powermax65 SYNC Plasma Cutter w/ CPC Port, 25...

$4,175.00

View

Powermax65 SYNC system, 200-600V 1/3-PH, CSA, CPC port, 180 degree machine torch, 7.6m (25

Powermax65 SYNC Plasma Cutter w/ CPC Port, 25...

$4,500.00

View

Powermax65 SYNC Plasma Cutter w/ CPC Port, 25...

$4,275.00

View

Powermax65 SYNC system, 200-600V 1/3-PH, CSA, CPC port, 75 degree handheld torch, 15.2m (50

Powermax65 SYNC Plasma Cutter w/ CPC Port, 50...

$4,400.00

View

Powermax65 SYNC system, 200-600V 1/3-PH, CSA, CPC port, 180 degree machine torch, 15.2m (50

Powermax65 SYNC Plasma Cutter w/ CPC Port, 50...

$4,500.00

View

Powermax65 SYNC Plasma Cutter w/ CPC Port, 50...

$4,800.00

View

Powermax65 SYNC 200-600V CSA, CPC port, 75 degree 25

Powermax65 SYNC Plasma Cutter w/ CPC Port, Ha...

$5,300.00

View

Powermax65 SYNC, 200-600V 1/3 PH, CSA PCP Port - 083372

Powermax65 SYNC Plasma Cutter w/ CPC Port, Po...

$3,550.00

View

Powermax85 SYNC system, 200-600V, 1/3-PH, CSA, CPC & Serial Ports, 180 degree torch, 10.7m (35 Side

Powermax85 SYNC Plasma Cutter w/ CPC & Serial...

$5,800.00

View

Powermax85 SYNC, 200-600V 1/3 PH, CSA, plus CPC & Serial ports - 087215

Powermax85 SYNC Plasma Cutter w/ CPC & Serial...

$5,000.00

View

Powermax85 SYNC system, 200-600V 1/3-PH, CSA, CPC port, 75 degree handheld torch, 7.6m (25

Powermax85 SYNC Plasma Cutter w/ CPC Port, 25...

$5,450.00

View

Powermax85 SYNC system, 200-600V 1/3-PH, CSA, CPC port, 180 degree machine torch, 7.6m (25

Powermax85 SYNC Plasma Cutter w/ CPC Port, 25...

$5,550.00

View

Powermax85 SYNC system, 200-600V 1/3-PH, CSA, CPC port, 180 degree machine torch, 15.2m (50

Powermax85 SYNC Plasma Cutter w/ CPC Port, 50...

$6,050.00

View

Powermax85 SYNC system, 200-600V 1/3-PH, CSA, CPC port, 75 degree handheld torch, 15.2m (50

Powermax85 SYNC Plasma Cutter w/ CPC Port, 50...

$5,700.00

View

Powermax85 SYNC Plasma Cutter w/ CPC Port, 50...

$5,800.00

View

Powermax85 SYNC 200-600V 1/3-PH, CSA, CPC port, 75 deg 25

Powermax85 SYNC Plasma Cutter w/ CPC Port, Ha...

$6,300.00

View

Powermax85 SYNC, 200-600V 1/3 PH, CSA, plus CPC port - 087214

Powermax85 SYNC Plasma Cutter w/ CPC Port, Po...

$4,775.00

View

Powermax85 SYNC system, 200-600V, 1/3-PH, CSA, CPC and Serial Ports, 180 degree torch, 7.6 (25

Powermax85 SYNC w/ CPC & serial ports, 25' 18...

$5,750.00

View

Consumables

Hypertherm cartridge: SmartSYNC or adapter 30-45 A mechanized FineCut - 428926

FineCut Hypertherm SmartSYNC mechanized cartr...

$55.00

View

Hypertherm cartridge: SmartSYNC or adapter 105 A mechanized cutting - 428936

SmartSYNC mechanized cartridge (105 A ) #4289...

$57.00

View

Hypertherm cartridge: SmartSYNC or adapter 45 A mechanized cutting - 428925

SmartSYNC mechanized cartridge (45 A) #428925

$53.00

View

Hypertherm cartridge: SmartSYNC or adapter 65 A mechanized cutting - 428930

SmartSYNC mechanized cartridge (65 A ) #42893...

$55.00

View

Hypertherm cartridge: SmartSYNC or adapter 85 A mechanized cutting - 428934

SmartSYNC mechanized cartridge (85 A ) #42893...

$55.00

View

W850-115 Metabo Angle Grinder #601232420

Angle Grinder W850-125 #603608420

$73.99

View

BSX Welders Backpack, Tool Bag, Gig Bag #GB10...

$119.25

View

Classic Cloth #244751

$29.70

View

MILLER HANDY SHEET METAL GUAGE KEY RING PART# 229895

MILLER HANDY SHEET METAL Gauge KEY RING #2298...

$6.34

View

Nemesis Safety Glasses Blue Mirror lens #1448...

$6.25

View

Nemesis Safety Glasses Smoke/Mirror #25688

$6.25

View

Product Questions and Answers

Q - Which consumables work with the Hypertherm SmartSYNC mini-machine torch? A - SmartSYNC mini-machine torches work with gray machine torch consumable cartridges. Powermax 65/85/105 SYNC machines work with cartridges up to 65 A, 85 A and 105 A, respectively.

Q - How are SmartSYNC mini-machine torches intended to be used? A - Hypertherm mini-machine torches are perfectly suited for use with CNC cutting tables, track cutters, and pipe-cutters where regular mechanized torches are too long.

Q - Can I use SmartSYNC mini-machine torches by hand? A - No. Hypertherm mini-machine torches are suitable for use with CNC machines only.

Q - Can SmartSYNC mini-machine torches be used for robotics applications? A - Yes! SmartSYNC robotic/mini torches are lightweight, small and contain built-in positioning features, making them a better choice for light arm robotics applications.

Q - When does it make sense to choose a full-length machine torch over a mini-machine torch? A - SmartSYNC full-length machine torches offer a wider range of positioning depths, making them applicable to a wider variety of CNC cutting tables, track cutters, and pipe-cutters where longer length is not an issue.

Q - Can SmartSYNC mini-machine torches be used with legacy Powermax 65/86/105 machines? A - No. Hypertherm SmartSYNC torches are intended solely for use with Powermax SYNC plasma cutters.
