POWER MIG® 215 MPi™ #K4876-1 - Specifications |
Phase 1: Input Voltage #1 (Voltage/Phase/Hertz) |
120/1/60 |
Phase 1: Rated Output #1A (Current/Voltage/Duty Cycle) |
MIG: 105A/19.25V/40% 80A/18V/100% |
Phase 1: Rated Output #1B (Current/Voltage/Duty Cycle) |
TIG: 130A/15.2V/40% 100A/14V/100% |
Phase 1: Rated Output #1C (Current/Voltage/Duty Cycle) |
Stick: 85A/23.4V/40% 60A/22.4V/100% |
Phase 1: Input Current at Max Rated Ouput #1 (Current) |
22A |
Phase 1: Input Voltage #2 (Voltage/Phase/Hertz) |
230/1/60 |
Phase 1: Rated Output #2A (Current/Voltage/Duty Cycle) |
MIG: 215A/24.8V/30% 120A/20V/100% |
Phase 1: Rated Output #2B (Current/Voltage/Duty Cycle) |
TIG: 175A/17V/30% 110A/14.4V/100% |
Phase 1: Rated Output #2C (Current/Voltage/Duty Cycle) |
Stick: 175A/27V/30% 110A/24.4V/100% |
Phase 1: Input Current at MAX Rated Output #2 (Current) |
29A |
Machines Processes |
Stick (SMAW) Flux-Cored (FCAW) TIG (GTAW) MIG (GMAW) |
IEC Rating |
IP21S |
Max Rating |
220A |
Output Range by Mode |
MIG: 20-220A |
Number of Operators per Machine |
1 |
Machines Communication Technology |
digital |
Work Lead Connector Type |
Dinse |
Welding Gun Cable Assembly Length |
Magnum PRO 175L |
Work Cable Length |
10 FT |
Spool Gun Compatible (Duty) |
Light |
Wire and TIG Feeders |
UI type |
TFT - Graphic |
Wire Feeders Processes |
MIG |
Flux Cored |
Contact Tips Included |
Yes |
Maximum Wire Thickness |
0.045 in (1.1 mm) |
Minimum Wire Thickness |
0.025 in (0.6 mm) |
Sample MIG Wire Included |
Yes |
Input Voltage |
120/230 |
Input Current |
120V: 15A, 230V: 15.9A |
Input Hertz |
60 |
Input Power |
120/230/1/60 |
Input Phase |
1 |
Mode Icon |
CC/CV |
Output Range |
120V: 20-140A DC 230V: 20-220A DC Max. OCV : 56V |
Polarity |
DC |
Rated Output |
120V: 105A/19.3/40% 230V: 215A/24.8V/30% |
Typical Application |
Automotive Brewery Distillery General Fabrication Maintenance & Repair Repair Welding |
Warranty |
3 Years |
