Miller Big Blue® 800 Duo Pro #907751

Part Numbers: 907751
UPCs: 715959656900

Included with your purchase: ()

Welder machine Miller Big Blue® 800 Duo Pro heavy duty
Miller Big Blue® 800 Duo Pro #907751
Miller Classic Series Welding Helmet with ClearLight™ Lens Technology, VS Black #287803
FREE!
Miller Classic Series Welding Helmet wit...
Welders Supply cup holder
FREE!
Welders Supply Magnetic Cup Holder
Black Stallion Split Cowhide Gloves
FREE!
Black Stallion Split Cowhide Stick Glove...
Choose Options
American Welder T-Shirt - Back
FREE!
Welders Supply T-Shirt & Stickers
$50,649.00 + Free Shipping $50,649.00*
SAVE $0.00
$50,649.00 + Free Shipping $50,649.00*
SAVE $0.00

Call 844-682-0205 or CHAT for more options

Welding type:

MIG

MIG

TIG

TIG

Stick

Stick

Engine Driven

Engine Driven

Material type:

Mild Steel

Mild Steel

Stainless Steel

Stainless Steel

Aluminum

Aluminum

Fuel Type:

Diesel

Diesel

  • Multi-Process
  • Multi-Phase
  • Engine Driven
  • 3-Year Warranty

Miller Big Blue® 800 Duo Pro #907751

Miller’s Big Blue® 800 Series is the most powerful lineup of diesel welder/generators in the industry. If you want more power, the Duo Pro packs 800 amps of weld power and 27,000 watts of peak generator power. Plug in additional inverters and the Duo Pro becomes a multi-operator platform!

The digital meters are equipped with SunVisionTM technology that allows welding parameters to be viewed more clearly at any angle – especially in direct sunlight. With ArcReach® Remote Control Technology, the Duo Pro allows for remote control of the power source without a control cord. This means reduced maintenance, less time troubleshooting problems from damaged control cords, and no more costly control cord repairs. And with an HD powder coat with zinc-rich primer, your Miller Big Blue® Duo Pro is protected from rust and corrosion, so you can rely on it for years to come.

A complete multi-process & multi-operator welder/generator that delivers two independent pipe quality arcs in one complete package. Upgrade to the SF model to unlock advanced RMD® & Pulsed MIG processes with the FieldPro™ Smart Feeder.

What's Included:

  • ArcReach® Remote Control Technology
  • Vandalism Lockout Kit
Check out the wide selection of welding machines including MIG welders, TIG weldersStick welders and Gas welding & cutting equipment available at Welders Supply Company.

Other versions of the Big Blue 800:

Processes:

  • Air Carbon Arc Cutting and Gouging (CAC-A)
  • Flux Cored (FCAW)
  • MIG (GMAW)
  • Stick (SMAW)
  • Pulsed MIG (GMAW-P)
  • RMD
  • TIG DC (GTAW-DC)

Miller Big Blue 800 Duo Pro Specifications:

Industries Interests Construction
Cross Country Pipeline
Infrastructure
Maintenance and Repair - Field Operations
Mechanical Contracting
Pipe Fabrication / Construction
Work / Service Trucks
Carbon Diameter 1/2 in (12.7 mm)
Cold Weather Starting Aids Engine Block Heater
Glow Plugs
Current Type DC
Engine Brand Deutz
Engine Compliance T4F
Engine Idle Speed 1350 RPM
Portability Lift Eye (Standard)
Trailer (Optional)
Fork Pockets
Engine Weld Speed 1800 RPM
Fuel Tank Size 25 Gallon
Net Height 46 in
Fuel Type Diesel
Net Length 69.5 in
Horsepower 65.7 hp
Max Open Circuit Voltage 85 VDC
Net Weight 1870 lbs
Weldable Metals Steel
Stainless Steel
Net Width 28.5 in
Single Phase Generator Continuous Power 12000 W
Warranty Engine Warranties
Miller's True Blue Warranty
Single Phase Generator Peak Power 15000 W
Sound Rating Idle: 71.3 dB / Weld: 78.9 dB
Three Phase Generator Continuous Power 20000 W
Three Phase Generator Peak Power 27000 W
Amperage Range 20 - 800

SHIPPING DIMENSIONS

Height: 48.00 Inches
Width: 30.00 Inches
Length: 71.00 Inches
Weight: 1920 Lb(s) 0 Oz

Product Questions and Answers


Q - How loud is it? A - Idle: 71.3 dB / Weld: 78.9 dB
Q - Will it start in cold weather? A - Yes, it has an engine block heater and glow plugs built in to assist with engine starting in cold weather.
