Miller S-74D Digital Wire Feeder Control Box #300882

Miller S-74D 300882

Wire feeder control box used in conjunction with a remote wire drive motor assembly.

Features:

Multiple Configurations

• Single- and dual-wire models with 8-, 12- or 16-foot booms are sized to accommodate a variety of weld cell layouts (16-, 24- or 32-foot diameter work area).

Maximize Work Area

• Counterbalance design makes it easy to position boom and 360-degree rotation and 60-degree lift angle maximizes work area.

Cable Management

• In-boom cable routing organizes hoses and cables for a cleaner work environment.

Be sure to view Welders Supply Company’s full selection welding machines including of Mig welders, Tig welding machines, and Stick welders available at the best prices online!

Processes

• MIG (GMAW)
• Flex Cored (FCAW)

General Specifications

Input Circut Welding Rating: 750A at 100% duty cycle

Power Source Compatibility: CV

Wire Feed Speed: 50-780 ipm

Wire Diameter: Flux Cored-0.094 in

                          Aluminum-0.094 in

Net Width: 10 in

Net Height: 9 in

Net Length: 13 in

Net Weight: 10 lbs

Warranty: 3 years, Miller True Blue Warranty

• Miller S-74D 300882 specs
