Miller Dynasty 280 DX (Auto-Line 208-575), CPS, VS #907514007

Part Number: 907514007
UPC: 715959661560
1 Review
This Item Has Been Discontinued and has been replaced by Dynasty® 300 Multiprocess Welder #907819 - Level up today!

Welding type:

MIG

MIG

TIG

TIG

Stick

Stick

Power supply:

220V Single Phase

220V Single Phase

220V 3 Phase

220V 3 Phase

460V

460V

Material type:

Mild Steel

Mild Steel

Stainless Steel

Stainless Steel

Aluminum

Aluminum

  • MIG Welding
  • Stick Welding
  • TIG Welding
  • Multi-Phase
  • 220V
  • 460V
  • 3-Year Power Warranty

Included with the Dynasty 280 DX, CPS Multiprocess Welder #907514007

  • Dynasty 280 DX Multiprocess
  • 8 ft. (2.4 m) Primary Cord
  • Adjustable Shoulder Strap
  • (2) 50 mm Dinse-style Connectors
  • (2) Dinse/Tweco Adapters (042465)
  • Quick Reference Guide

MIG

CV output of the power source gives this unit MIG process capabilities when paired with a SuitCase® X-TREME™ 8VS (or other voltage-sensing feeder).

Auto-Line™ Power Management Technology

Allows for any input voltage hookup (208–575 V) with no manual linking, providing convenience in any job setting. Ideal solution for dirty or unreliable power.

Blue Lightning™

High-frequency (HF) arc starter for non-contact arc initiation. Provides more consistent arc starts and greater reliability compared to traditional HF arc starters.

Fan-On-Demand™

The cooling system operates only when needed, reducing noise, energy use and the amount of contaminants pulled through the machine.

Cooler-On-Demand™

feature operates the auxiliary cooling system only when needed, reducing noise, energy use, and airborne contaminants pulled through the cooler.

Pro-Set™

Eliminates the guesswork when setting weld parameters. Use Pro-Set when you want the speed, convenience, and confidence of preset controls. Simply select the feature and adjust until Pro-Set appears on the display.



Not included:

View all TIG welders, Miller welding machines, and all welding machine accessories for more great deals!

Miller Dynasty 280 DX, CPS Multiprocess General Specifications

Product Name Dynasty® 280 DX, CPS Multiprocess
Industries Interests Construction
Education / Training
Infrastructure
Maintenance and Repair - Field Operations
Mechanical Contracting
Pipe Fabrication / Construction
Shipbuilding
Work / Service Trucks
Weldable Metals Aluminum
Specialty Metals
Stainless Steel
Steel
Carbon Diameter 3/16 in (4.8 mm)
Input Voltage 208 V
220/230/240 V
380/400 V
460/480 V
575 V
Input Phase 1- and 3-Phase
Input Hz 50 / 60 Hz
Current Type AC / DC
Max Open Circuit Voltage 60 VDC
Net Width 8.6 in
Net Height 13.6 in
Net Length 22.5 in
Net Weight 55 lbs
Warranty 3 Years
Portability Running Gear / Cart (Optional)
Strap
Weld Output CC / CV

SHIPPING DIMENSIONS

Height: 13.00 Inches
Width: 17.00 Inches
Length: 27.00 Inches
Weight: 58 Lb(s) 0 Oz

Manufacturer Reviews

JT
52lbs and 280 amps ac/dc how can you beat it.waveform and balance adjustment it really user friendly would highly recommend the dynasty 280

Product Questions and Answers


Q - Will the ArcReach SuitCase work with this? A - Miller advises that the Dynasty 280DX isn't capable of ArcReach control.
Q - What input power does this need? A - 208 - 575 V, 1-phase or 3-phase
